EDGE系列
+ 查看更多

Edge

Rockchip RK3399 + 314 Pin金手指

了解更多

Edge-V

Rockchip RK3399 + VIM外形

了解更多

Captain

Edge底板

了解更多

Rockchip主板对比

		Edge + Captain	Edge-V	NanoPi-M4	NanoPC-T4
Memory	RAM	LPDDR4	LPDDR4	DDR3 / LPDDR3	LPDDR3
	eMMC	onboard, 16/32/128GB	onboard, 16/32/128GB	Socket	onboard, 16GB
	SPI Flash	16MB	16MB	-	-
Display	USB-C Display	Yes	Yes	-	Yes
	HDMI	Yes	Yes	Yes	Yes
	MIPI-DSI	2 Channels	2 Channels	1 Channels	2 Channels
	eDP	Yes	Yes	-	Yes
	Touch Panel Connector	0.5mm Pitch 10 Pin	0.5mm Pitch 10 Pin	-	-
Power Supply	Over USB-C	Dual USB-C USB PD(5~20V)	Dual USB-C USB PD(5~20V)	One USB-C Fixed 5V	One USB-C Not Available
	Over Li-ion Battery	Yes	Yes [1]	-	-
	Over DC Jack	12V	-	-	12V
Sensors	Gesture Control	APDS-9960	APDS-9960	-	-
Sensors	6-Axis Motion Tracking	ICM-20602	ICM-20602	-	-
Connectivity	RSDB Wi-Fi [2]	Yes	Yes	-	-
	Bluetooth	V4.1/V5.0	V4.1/V5.0	V4.1	V4.1
	Wake-on-Lan	Yes	Yes	-	-
Misc	PCI-E	Full 4 lanes M.2 Socket	Full 4 lanes M.2 Socket	GPIO Header	Full 4 lanes M.2 Socket
	USB available on GPIO Header	Yes	Yes	-	-
	PWM Cooling Fan Header	Yes	Yes	-	Yes
	User Buttons	15 (Game Pad)	3	-	4
	IR Receiver	Dual Channels	Dual Channels	-	One Channel
	Audio Codec	ALC5651	-	-	ALC5651
	Buzzer	Yes	-	-	-
	USIC	Yes	-	-	-
Khadas Only	Khadas TST [3]	Yes	Yes	-	-
Khadas Only	Programable MCU [4]	Yes	Yes	-	-
Design	PCB Designing	10 Layers	10 Layers	8 Layers	10 Layers
Design	Board Dimensions	116.0 x 82.0 x 13.5MM	82.0 x 58.0 x 13.5MM	87.2 x 58.5 x 19.0MM [5]	102 x 68.2 x 20.2MM [5]

[1] 电池模块需要内置的充电电路。
[2] RSDB: 实时同步双频，使Edge（仅限Pro＆Max）和其他设备可以同时在两个频带上发送和接收数据。
[3] Khadas TST允许即使在引导加载程序损坏的情况下依然能够进入升级模式。
[4] MCU: 电源管理，用于自定义的EEPROM和引导媒体（SPI Flash或eMMC）、KBI设置。
[5] 尺寸测量包含端口。
